Features: | Durability | Advantage: | High Hardness |
---|---|---|---|
NItriding Depth:: | Customized | Material: | 38CrMoAlA Or Customized |
Highlight: | anti counterfeiting Embossing Roller,custom pattern Embossing Roller,38CrMoAlA Embossing Roller |
Customization CNC Embossing Roller For Wood Pvc Paper And Leather Fabric
Embossing roller is suitable for pressing concave and convex patterns such as plastic sheet, film, aluminum foil, leather, hard board, wallpaper, floor tile, glass, paper, etc., to improve the product surface aesthetics, strengthen anti-counterfeiting, trademark protection and other effects. And according to customer requirements to develop different patterns of embossing rollers.
The roller is customized according to customer specified data, size, pattern, surface treatment and other products.
Production Process:
1. The material of the roller body is generally selected from high-quality seamless steel tubes (special materials can be customized according to user needs). After boring and grinding the inner hole, the thickness of the tube wall is uniform, and then it is made by welding, stress relief treatment, turning, grinding, and finishing;
2. Correct the static balance and dynamic balance treatment; the coaxiality of the finished roller ≤0.02mm;
3. According to the pattern, different processing techniques are adopted to achieve a clear pattern, exquisite pattern, rich levels and precise size of the extruded product.
4. The final surface is plated with hard chrome or other treatments, and the hardness can reach HRC58-62.
The main technical parameters:
Name | Embossing roller |
Engraving way | Laser engraving |
Surface treating | Chrome plating |
Surface hardness | HV1100/HRC 62 |
Heating temp | Max 300, according to customer's heating way |
Pattern | We can custom |
Pattern | According to your requirements, CNC engraving |
Printing Cylinder Circumference | 100-1500mm |
Surface Hardness | ≥C58-62,with strong corrosion resistance |
Roughness | ≥ Ra0.16, without air hole or groove |
Temperature difference | ≤±1°C |
Thermal deformation | ≤0.01mm |
Concentricity | 0-15microns |
Straightness | ≤0.2mm |
Cylindricity | ≤0.2mm |
Application Range:
