Customize CNC Embossing Roller Corrosion Resistance

Customize CNC Embossing Roller Corrosion Resistance

  • Customize CNC Embossing Roller Corrosion Resistance
Customize CNC Embossing Roller Corrosion Resistance
Product Details:
Place of Origin: ChinaA
Brand Name: Paper towels to pressure
Model Number: SYKEY-YSL
Payment & Shipping Terms:
Minimum Order Quantity: A set of
Price: usd
Packaging Details: Export standard
Delivery Time: According to actual time
Payment Terms: T/T
Supply Ability: Custom number
Contact Now
Detailed Product Description
Product: Customize Ultrasonic Welding Mold Shaping Mode:: Die Casting
ODM: Accept Function: Welding, Embossing, Triming
High Light:

CNC Embossing roller

,

corrosion resistance Embossing roller

,

hard chrome Embossing roller

Customization CNC Embossing Roller For Wood Pvc Paper And Leather Fabric



1. High quality material-Hight-speed tool steel.
2. Strict CNC engraving.
3. Long life-time.
4. Mature process.
Technical Specifications
Adopt import high-speed tool steel, The hardness can be HRC60-HRC62 after full vacuum heat treatment. Blade height and angle can be adjusted according different application and material to get the excellent cutting result and a long lifetime.



Production Process:

1. The material of the roller body is generally selected from high-quality seamless steel tubes (special materials can be customized according to user needs). After boring and grinding the inner hole, the thickness of the tube wall is uniform, and then it is made by welding, stress relief treatment, turning, grinding, and finishing;

2. Correct the static balance and dynamic balance treatment; the coaxiality of the finished roller ≤0.02mm;

3. According to the pattern, different processing techniques are adopted to achieve a clear pattern, exquisite pattern, rich levels and precise size of the extruded product.

4. The final surface is plated with hard chrome or other treatments, and the hardness can reach HRC58-62.



The main technical parameters:

Name Embossing roller
Engraving way Laser engraving
Surface treating Chrome plating
Surface hardness HV1100/HRC 62
Heating temp Max 300, according to customer's heating way
Pattern We can custom
Pattern According to your requirements, CNC engraving



Printing Cylinder Circumference 100-1500mm
Surface Hardness ≥C58-62,with strong corrosion resistance
Roughness ≥ Ra0.16, without air hole or groove
Temperature difference ≤±1°C
Thermal deformation ≤0.01mm
Concentricity 0-15microns
Straightness ≤0.2mm
Cylindricity ≤0.2mm



Application Range:

  • Paper industry:Art paper, wallpaper, paper towels, cigarettes, beer foil paper, various wrapping paper, special paper.
  • Plastic industry: artificial leather, PU leather, various plastics (films, sheets, sheets), plastic carpets, car interior carpets, placemats, bronzing hollow tablecloths, advertising light box cloths, Oxford cloth composites, and various types of transmission belts.
  • Rubber industry: rubber carpets, sole patterns and various industrial transmissions, etc.
  • Non-woven fabric industry: various flower-shaped hot-rolled non-woven fabrics
  • Textile industry: embossing on various textile materials, sizing of interlining cloth, compounding of interlining cloth
  • Architectural hardware industry: architectural decorative panels, non-slip aluminum panels, flowered glass, wood-plastic panels, door covers, and embossing on stainless steel decorative pattern boards.
